Eaton MEM MCH363 455345-005 63A 240V 10kA Triple Pole 3 Pole Type C MCB

$123.00

SKU: MR_MCH363-NEW

Availability: 11 item(s)

Qty:

Enter your destination to get a shipping estimate

Details

Eaton MEM MCH363 455345-005 63A 240V 10kA Triple Pole 3 Pole Type C MCB

Item is New.

Key Technical Specifications

Current Rating: 63 Amp
Number of Poles: 3 Pole (Triple Pole / Three Phase)
Tripping Characteristic: Type C Curve (suited for inductive loads with high inrush currents)
Voltage Rating: 240V / 415V AC (Suitable for 230/400V systems)
Breaking Capacity: 10kA (per IEC/EN 60898) / 15kA (per IEC/EN 60947-2)
Impulse Withstand Voltage: 5kV
Energy Limiting Class: Class 3

Physical & Installation Data

Mounting Type: Top-hat DIN Rail mount
Terminal Capacity: Box clamp terminals accepting solid or multi-wired cables up to 25mm²
Busbar Compatibility: Pin and comb type busbar systems
Dimensions: 54mm (Width) x 75mm (Width/Height) x 80mm (Depth)
Ingress Protection: IP20 rated (protection against solid particles >12mm)
Operating Temperature: -25°C to +55°C (Calibrated at 40°C)

Additional Features

Contact Position Indicator: Features a positive contact flag indicator (Red for ON, Green for OFF)
Safety Design: Includes a box clamp barrier to prevent incorrect cable or busbar insertion

Condition Description	An item that has been restored to working order by the eBay seller or a third party not approved by the manufacturer. This means the item has been inspected, cleaned, and repaired to full working order and is in excellent working condition. This item may have cosmetic blemishes and may or may not be in original packaging. See the listing description for full details.
