Details
Item is Used with Normal Wear and Tear, Tested and Working.
INPUT
- Input Phase: Single-Phase
- PDU Input Voltage: 120
- Recommended Electrical Service: Two single-phase 20A 120V circuits
- Maximum Input Amps: 16
- Maximum Input Amps Details: Agency de-rated to 16A continuous
- Input Connection Type: Primary: L5-20P and Secondary: C20 inlet and detachable C19-to-L5-20P cord set and adapters
- PDU Plug Type: (2) NEMA 5-20P; (2) NEMA L5-20P
- Input Cord Details: Set of two L5-20P cord sets with two 5-20P adapters enable connection to separate PRIMARY and SECONDARY power sources
- Input Cord Length (ft.): 12
- Output Capacity Details: 1.92kW (120V) / 16A total capacity; 16A max per outlet
- Frequency Compatibility: 50 / 60 Hz
- Output Receptacles: (16) 5-15/20R
- Output Nominal Voltage: 120V
- Customized Load Management Receptacles: 16 individually switched output receptacles
- Front Panel LCD Display: Digital display reports total PDU output current in amps
- Switches: Recessed reset button for rebooting SNMP management card without affecting AC output to connected equipment
- LED Indicators: 16 front panel LEDs display power on / off status for each outlet, plus 2 LEDs for power status on each input line cord; Digital current meter display shows the amount of power consumption in amps for entire output of PDU. Pre-installed WEBCARDLX provides Ethernet Link and Status LED's for network activity along with a system status LED for monitoring system operation.
- Material of Construction: Metal
- Rack Height: 1U
- Form Factors Supported: 1U rackmount
- Minimum Required Rack Depth (inches): 19.5
- PDU Form Factor: Horizontal (1U)
- Unit Dimensions (hwd / in.): 1.750 x 17.500 x 14.500
- Unit Weight (lbs.): 12.20
- Operating Temperature Range: 32° to 104°F (0° to 40°C)
- Storage Temperature Range: -22° to 122°F (-30° to 50°C)
- Relative Humidity: 5% to 95% non-condensing
- Operating Elevation: 0-10000 ft. (0-3000 m)
- Power Alert Software: LX Platform Interface: Power Alert Device Manager
- Communications Cable: Micro-USB- to-USB A configuration/console Access cable
- Network Monitoring Port: RJ45 Network port, Micro-USB Configuration port, USB A port supports a variety of Envirosense2 environmental and control modules. See Accessories>Management Hardware section for more information about these modules.
- SNMP Compatibility: Pre-installed LX platform interface provides remote monitoring via Java-free HTML5 web interface, telnet, SSH and SNMP management systems
- Network Compatibility: 10 Mbps; 100 Mbps (Fast Ethernet)
- Grounding: Rear grounding lug
- High Availability PDU Features: Auto Probe Monitoring and Reboot (included); Auto-Transfer Switching; Auto Load Shedding
- Product Certifications: CSA (Canada); NOM (Mexico); UL 60950-1
- Product Compliance: RoHS; FCC Part 15 Class A (USA); Trade Agreements Act (TAA
Specifications
| Condition Description | An item that has been restored to working order by the eBay seller or a third party not approved by the manufacturer. This means the item has been inspected, cleaned, and repaired to full working order and is in excellent working condition. This item may have cosmetic blemishes and may or may not be in original packaging. See the listing description for full details. |
|---|
