HP Agilent 8114A 100V 2A 15MHz High Power Pulse Generator OPT 001 FOR PARTS

SKU: AR_Agilent 8114A Parts

Availability: 1 item(s)

Estimate Shipping Cost

Enter your destination to get a shipping estimate


Up for sale is a used HP Agilent 8114A 100 V / 2 A / 15 MHz High Power Pulse Generator.

It power on but has bad CPU and power boards. Might have additional issues as well. Sold For Parts.

It shows signs of use with scratches and small dents on the chassis.

OPT 001 Variable Baseline ± 25 V

Original Manufacturer Description:

Today's telecommunications and computer systems increasingly take advantage of devices such as laser and IR diodes, EEPROMS and flash memories which operate at high voltages or currents.

Fast, clean positive or negative pulses up to 100 V at frequencies up to 15 MHz

User-definable limits for voltage, current and duty cycle

TLL input: allows the output to be enabled or disabled

Transitions < 12 ns for high impendance source into 50 Ohm load. Baseline OV.

In 50 Ohm/50 Ohm mode, the maximum voltage is 50 Vpp with transitions < 7ns
